Aventa In-Line 100T is a mixed flow fan (with LED lamp). Quiet and powerful, high performance up to 52 l/sec. Two speed operation with basic and timer models. Ductable up to 6m and supplied with a mounting bracket. Aventa 100mm in-line mixed flow fans are available in high-performance two speed versions. They are less bulky than large in-line centrifugal fans and can be installed in loft spaces or service shafts. This range is specially designed for residential applications requiring remote extraction. It is also supplied with a mounting bracket for quick and easy installation on wooden joists and panels. The inlet/outlets are compatible with flexible and rigid pipe runs up to 3m either side of the fan (6m).The units operate manually from an (optional) three position switch (off/low/high) or with adjustable timer version (2 to 30 minutes)
Application:
Aventa 100mm in-line mixed flow fans (with LED lamp) are suitable for removing damp moist air, odours and airborne pollutants from toilets, bathrooms, en-suites and shower rooms without windows or natural ventilation.
Features:
Designed for longer duct runs
High pressure low noise
Compact and quiet in operation
Two speed (normal and boost)
Access to motor and impeller without dismantling ductwork
12v DC, Cool White, LED Lamp (4 Watts/220 Lumens)
CE, IPX4 rating and double insulated
Supply or extract air
Complies with Building Regulations
Adjustable timer
3 Year warranty
Chrome Bezel (9041480) available
Replacement LED Bulb (90001384) available - Bulb: MR16 S24 B 4W 12V AC/DC 6000K
